MIL-STD-810G 시험항목

18 Aug 2017 Comments
Off

아래는 MIL-STD-810G Part Two (II)에서 기술된 시험방법들 입니다.

MIL-STD-810G Method 500.6 Low Pressure (Altitude)
MIL-STD-810G Method 501.6 High Temperature
MIL-STD-810G Method 502.6 Low Temperature
MIL-STD-810G Method 503.6 Temperature Shock
MIL-STD-810G Method 504.2 Contamination by Fluids
MIL-STD-810G Method 505.6 Solar Radiation (Sunshine)
MIL-STD-810G Method 506.6 Rain
MIL-STD-810G Method 507.6 Humidity
MIL-STD-810G Method 508.7 Fungus
MIL-STD-810G Method 509.6 Salt Fog
MIL-STD-810G Method 510.6 Sand and Dust
MIL-STD-810G Method 511.6 Explosive Atmosphere
MIL-STD-810G Method 512.6 Immersion
MIL-STD-810G Method 513.7 Acceleration
MIL-STD-810G Method 514.7 Vibration
MIL-STD-810G Method 515.7 Acoustic Noise
MIL-STD-810G Method 516.7 Shock
MIL-STD-810G Method 517.2 Pyroshock
MIL-STD-810G Method 518.2 Acidic Atmosphere
MIL-STD-810G Method 519.7 Gunfire Shock
MIL-STD-810G Method 520.4 Temperature, Humidity, Vibration, and Altitude
MIL-STD-810G Method 521.4 Icing/Freezing Rain
MIL-STD-810G Method 522.2 Ballistic Shock
MIL-STD-810G Method 523.4 Vibro-Acoustic/Temperature
MIL-STD-810G Method 524.1 Freeze / Thaw
MIL-STD-810G Method 525.1 Time Waveform Replication
MIL-STD-810G Method 526.1 Rail Impact
MIL-STD-810G Method 527.1 Multi-Exciter Test
MIL-STD-810G Method 528.1 Mechanical Vibrations of Shipboard Equipment (Type I – Environmental and Type II – Internally Excited)

IP Code

IP Code에 대한 이해

IP 5K4K란?



IP Code는 보통 international protection Code로 알리어지거나 또는 Ingress protection으로 불려지고 있다. 모두 먼지와 물의 침투에 관한 등급 표기 방식이다.

각 규격 별로 약간의 다른 등급표기가 있으나 의미상 내용은 크게 다르지 않으나 유사한 세부적 분류의 표기법이 있다.

다음은 규격의 전부 또는 일부로써 IP code를 다루고 있는 규격 사례들이며 각 규격의 적용분야는 서로 다르지만 의도하는 목적은 같다.

  1. DIN EN 60068-2-18 ; Environmental testing: water
  2. DIN EN 60529; VDE 0470-1  ;Degrees of Protection provided by Enclosures (IP-Code)
  3. ISO 20653 Road vehicles — Degrees of protection (IP-Code) (replacing DIN 40050)
  4. MIL-STD-810G Rain Dust
  5. NEMA 250 : 전기공업협회
  6. RTCA/DO-160G ; Waterproofness
  7. VW 80000 ; Automotive





IP Code 표기법

IP X 0

의미

ISO 20653

DIN EN 60529

먼지에 대한 보호

0

0

no protection

1

1

먼지 ≥ 50mm

2

2

먼지 ≥ 12,5mm

3

3

먼지 ≥ 2,5mm

4

4

먼지 ≥ 1mm

5K

5

Dust(먼지) protected

6K

6

Dust(먼지) tight







IP 0 X
물의 침투에 대한 보호

ISO 20653

DIN EN 60529

0

0

1

1

2

2

3

3

4

4

4K

-

5

5

6

6

6K

 -

7

7

8

8

 -

9

9K

 -

APN_시험인증_IP_Code_IP4K5K

ASTM E119 Fire Testing

25 Mar 2016 Comments
Off

ASTM E 119

-  건물 건축 및 건축 재료의 화재 시험을 위한 표준 시험 방법

ASTM E84,  NFPA 285, UL 790, BS 476-6/7, NF P92-507, DIN 4102, EN 13501, GB 8624, BS 476-20,EN 1363 등 있으나 ASTM E119은 이들 보다 특별한 시험이다.



ASTM E 119 적용대상

  1. Bearing Walls and Partitions
  2. Columns
  3. Floors and Roofs
  4. Loaded Restrained Beams
  5. Nonbearing Walls and Partitions
  6. Protective Membranes in Wall, Partition, Floor, Roof Assemblies
  7. Solid Structural Steel Beams, Girders
  8. Structural Steel Columns



ASTM E 119 관련 참고 규격

  1. ASTM C 569 Indentation Hardness of Preformed Thermal Insulations
  2. ASTM E 176 Terminology for Fire Standards



ASTM E 119 측정 단계

  1. 1000°F (538°C) at 5 min
  2. 1300°F (704°C) at 10 min
  3. 1550°F (843°C) at 30 min
  4. 1700°F (927°C) at 1 h
  5. 1850°F (1010°C) at 2 h
  6. 2000°F (1093°C) at 4 h
  7. 2300°F (1260°C) at 8 h



HOSE STREAM TEST

소방수 분사 시험의 일종으로 정해진 압력으로 소방수를 방수한 후 그 결과를 확인함.

ASTM E 119 비교대상

BS 476-20 : Fire tests on building materials and structures – Method for determination of fire resistance of elements of construction

EN 1363 : Fire Resistance Tests



[참고] 규격별 구분.

1.     Cone Calorimeter
           - ASTM E1354
2.     ISMA
           - NFPA 285. ASTM E2307
3.     Large Scale Vertical Furnace
            – ASTM E119. ASTM E1966. NFPA 251. NFPA 252. NFPA 257. UL 9. UL 10B. UL 10C. UL 263.
4.     Roof Testing
           - ASTM E108. UL 790
5.     Small Scale
           - ASTM D635. ASTM D1929. ASTM D2843. ASTM E136. NFPA 701.
6.     Steiner Tunnel
           - ASTM E84. UL 723. CAN/ULC-S102. NFPA 255

시료의 사례)

ASTM E119_Wall_Construction_3Hrs_hose stream

ASTM E119 Fire Testing
