Archive for month: December, 2014

Synthetic turf

27 Dec 2014 Comments
Off

Product : Synthetic turf

아래는 UFGS 관련 인조잔디에 대한 적합성 시험항목입니다.

1. Yarn Number Based on Short-Length Specimens ASTM D1059-01

2. Tearing Strength of Fabrics by the Tongue (Single Rip) Procedure (CRE Testing Machine) ASTM D2261-11

3. Identification of Fibers in Textiles ASTM D276-00a (2008)

4. Tuft Bind of Pile Yarn Floor Coverings ASTM D1335-12

5. Tensile Properties of Yarns by the Single-Strand Method . Option A (Straight) ASTM D2256/D2256M-10

6. Ignition Characteristics of Finished Textile Floor Covering Materials ASTM D2859-06

7. Water Permeability of Geotextiles by Permittivity ASTM D4491 – 99a (2014)e1

8. Breaking Strength and Elongation of Textile Fabrics (Grab Test) ASTM D5034-09 (2013)

9. Binding Sites per Unit Length or Width of Pile Yarn Floor Coverings ASTM D5793-05

10. Tuft Height of Pile Floor Coverings ASTM D5823-05a11

11. Mass Per Unit Area of Pile Yarn Floor Coverings – Total Mass per Unit Area ASTM D5848-10e1 Section 7

12. Mass Per Unit Area of Pile Yarn Floor Coverings – Component Masses per Unit Area ASTM D5848-10e1 Section 8

13. Mass Per Unit Area of Pile Yarn Floor Coverings – Pile Yarn Mass per Unit Area ASTM D5848-10e1 Section 9

14. Critical Radiant Flux of Floor-Covering Systems Using a Radiant Heat Energy Source ASTM E 648-10e¹

15. Melting and Crystallization Temperature by Thermal Analysis ASTM E794-06 (2012)

16. Relative Abrasiveness of Synthetic Turf Playing Surfaces ASTM F1015-03 (2009)



Turkmenistan Certificate TDS

05 Dec 2014 Comments
Off

Turkmenistan Certificate TDS 인증서

TDS2

- 투르크메니스탄은 자국 내로 수입되는 제품에 대해  제품인증의 취득을 요구하고 있습니다. 특히측정에 사용되는 계측장비는 “Turkmenstandartlary.”의 관련 규정에 따라 교정되어야 합니다. 1998 년경, 투르크메니스탄으로 수입되는 식품류에 대해 위생관련 인증요구 사항이 발효되었습니다. 국가 위생 및 역학 검사기관(SSEI)이 적합성인증서를 발행하기 위한 시험을 수행하며 이러한 식품류에는 필수적으로 러시아 언어로 표기된 제품설명서를 부착하여야 합니다.





투르크메니스탄의 state system of certifcation의 인증조직구조 :

TDS1

  • The State agency for Certification of products and services
    (Glavgosinspektsiya Turkmenistan);
  • Bodies for certification of products and services;
  • Testing laboratories (centers)









강제인증 대상 :

  • 국가 표준 및 기타 문서에 따라 안전 및 보건, 품질 및 환경관련 주요 품목은 해당 규격 및 법규  TDS 1.2 에서 품목의  적함함을 보장토록 요구하는 모든  대상물품, 작업 및 서비스 품목을 강제 인증대상으로 규정하고 관리함.[ HS code  분류 목록의 최신 개정을 확인할 필요 있음. 문의바로가기  ]
  • 관련 규정에 의해 인증을 취득한 제품관련 정보는 State Certification Registry에 등록하고 제품에는 해당 마크를 부착하여야 함.

참고 :

  • 일상적 통관절차는 예상보다 다소 늦게 진행되며 엄격한 법적용 등으로 인해 관료적이라는 평판이 있음.
  • 품목의 가격타당성은 최고 상공 회의에 의해 참조되고 모든 품목은 수입전에 관련기관에 필수적으로 등록되어야 하며 이러한 절차를 처음 경험하는 경우 상당한 어려움이 있을 수 있음. [BIRJA etc.]
  • 물품의 수출 수입에 관련하여 State Commodity and Raw Materials Exchange (SCRME) : [물품 및 원자재 거래소]에 등록하여야 함.
  • 일부 투자  또는 Civil construction 의 경우, Ministry of Economy and Development에 의한 승인이 요구될 수 있음.
  • 상사 분쟁의 경우, Turkmenistan은 2012년 현재까지 New York Convention on International Arbitration에 가입하지 않아 상사간 분쟁을  중재할 조직이 없음.





ASTM D6878 – on TPO membrane Analysis

건축자재 인증 및 시험 관련 규격

Download : Analysis of one TPO membrane per ASTM D6878_D6878M-13

Analysis of one TPO membrane per ASTM D6878/D6878M-13.

아래는 적용되는 분석기법입니다.

    1. ASTM D 6878/D : Brittleness Point per ASTM D2137, Method B
    2. ASTM D 6878/D : Ozone Resistance per ASTM D 1149 (Exposed to 100 mPa ozone in air @40°C, wrapped around a 3″ mandrel for 166 hrs exposure) – OUTSOURCED
    3. ASTM D 6878/D : Breaking Strength per ASTM D751, grab method – MD
    4. ASTM D 6878/D : Breaking Strength per ASTM D751, grab method – XMD
    5. ASTM D 6878/D : Elongation at Reinforcement Break per ASTM D751, grab method – MD
    6. ASTM D 6878/D : Elongation at Reinforcement Break per ASTM D751, grab method – XMD
    7. ASTM D 6878/D : Factory Seam Strength @ 2 in/min (12 in x 1 in specimen) per ASTM D751,grab method
    8. ASTM D 6878/D : Heat Aging, 5376 hrs (224 days) @ 116°C, per ASTM D573
    9. ASTM D 6878/D : Linear Dimensional Change, 6 hr @ 70°C (158°F), per ASTM D1204
    10. ASTM D 6878/D : Post Heat Aging: Breaking Strength per ASTM D751, grab method – MD
    11. ASTM D 6878/D : Post Heat Aging: Breaking Strength per ASTM D751, grab method – XMD
    12. ASTM D 6878/D : Post Heat Aging: Elongation at Reinforcement Break per ASTM D751, grab method – MD
    13. ASTM D 6878/D : Post Heat Aging: Elongation at Reinforcement Break per ASTM D751, grab method – XMD
    14. ASTM D 6878/D : Post Heat Aging: Tearing Strength, 2 in/min (8 in x 8 in specimen) per ASTMD751 – MD
    15. ASTM D 6878/D : Post Heat Aging: Tearing Strength, 2 in/min (8 in x 8 in specimen) per ASTMD751 – XMD
    16. ASTM D 6878/D : Post Heat Aging: Weight Change (mass)
    17. ASTM D 6878/D : Tearing Strength, 2 in/min (8 in x 8 in specimen), per ASTM D751 – MD
    18. ASTM D 6878/D : Tearing Strength, 2 in/min (8 in x 8 in specimen), per ASTM D751 – XMD
    19. ASTM D 6878/D : Thickness, Coating Over Fabric or Scrim (weathering side only) per ASTM D7635
    20. ASTM D 6878/D : Thickness, Sheet-Overall per ASTM D751
    21. ASTM D 6878/D : Water Absorption, 166 hrs @ 70°C (158°F) (mass) per ASTM D471 – Performed on top coating material ONLY
    22. ASTM D 6878/D : Weather Resistance per ASTM G 155 at 0.35 W/(m²•nm) at 340 nm (8000 hrs)
